Giant S XDHL
The Giant S XDHL is a wide range of industrial liquid coolers, compact V-shape single fan row, offering high capacity in a compact footprint with reduced power consumption and typically used in air conditioning, refrigeration and HVAC. The new product is also suitable for various process liquid cooling, food, plastics industry, etc. and power applications such as small-medium size gas or diesel engine coolers and fits even in severe environments. With a wide range of sound pressure level alternatives, these units are particularly suitable for noise sensitive environments.
What profile fits you best?
Select your Application
Which sector/application are you interested in?
Select your application to discover tailored features and benefits
Refrigeration
Air Conditioning (HVAC)
Technical features
- Main applications
The Giant S is a wide range of industrial liquid coolers, compact V-shape single fan row, offering high capacity in a compact footprint - Refrigerant
Glycol - Capacity range
up to 500 kW - Design pressure
10 bar - Fan-motors
High efficiency, low power consumption EC motors - Fan diameters
Ø 910 and 960 mm
- Refrigerant
- Glycol
- Capacity range
- up to 500 kW
- Design pressure
- 10 bar
Casing
- The body and frame are made of high quality C4-H galvanised steel, powder coated RAL 9003 (white) to make the product suitable for industrial environments.
- The structure is designed to ensure rigidity, thermal expansion and readiness to change the product from dry to wet working mode thanks to the optional water Adiabatic System PADs kit, which can be fully factory fitted or supplied as a retrofit.
Fan-Motors
- High efficiency, low power consumption EC motors are suitable for multiple voltage and frequency power supply and optimized for different noise levels.
- Fan diameters: Ø 910 and 960 mm
Options
- Aluplus (AP): Aluminum-Magnesium alloy coated with a special paint treatment to provide protection and corrosion resistance
- Cu fins
- Vibration dampers (VD)
- Coil protection grid (GR)
- Whisperer (WH)
- Special Radial fan motors (RAD)
- Electrical accessories:
- Isolator switch (IS)
- Basic switchboard, with fuse protection (ESB)
- Switchboard with automatic switch for each fan (ECCB)
- Switchboard with master controller regulation (ECCB+MC)
- Adiabatic System (AS) – available also as retrofit kit
Design pressure
- Max operating pressure 10 bar.
Coil
- Copper tube circuit design optimised for fluid flow.
- Highly efficient fin tube pattern increases heat transfer performance.
- Standard Aluminium fins.
- Various materials and spacings available.
- Unique coil construction provides protection against vibration and thermal expansion thanks to the patented SafeTube system.
Certifications
- The LU-VE quality system is in accordance with ISO 9001. All products are manufactured according to PED regulations. LU-VE participates in the ECP program for HE. Check ongoing validity of certificate:
www.eurovent-certification.com
