Glass door system for negative temperature
The most diffused
Line-up STD Line
Line-up STD Line
The Max product range for wall freezers offers the highest reliability for those looking for a product created with traditional technology, simple and easy to use in any operating environment.
The thousands of units produced and active on the market constitute the major guarantee of absolute efficiency.
What profile fits you best?
Framed doors configuration
Aluminium framed glass door
- Exclusive design and full height comfortable grip handle
- Left to right hand and vice versa reversible door
- Swing door made of triple glass with security exterior layers according to UNI 12150 standard
- Glass standard heating: 220V 100W/SQM (any other voltage and wattage available on demand)
- Aluminium frame standard heating: 220V 7.5W/LMT (any other voltage and wattage available on demand)
- Adjustable self-closing action by torsion bar
- Manual open wide door lock
Standard heating master frame
- Silver satin aluminium insulated by RAL 9005 PVC covers
- Any frame is adapted to receive aluminium framed or full glass doors by LUVE TGD
- Available configurations: 1, 2, 3, 4 and 5 openings
- LED on board or LED pre-wired configuration available
Top Advantages
Extreme reliability
hundred thousand of products operating in the market
Perfect adaptability
To any operating conditions
The world-wide solution
available with any voltage predisposition
World-wide adaptability
Extreme reliability
Customised handles and colours
Full doors configuration
Full glass door
- Full glass door with customizable exterior RAL 9005 silk screen (Other colours available on demand)
- High fashion Italian design and full height or short comfortable grip handle
- Left to right hand reversible door
- Swing door made of triple glazing glass with security exterior layers according to UNI 12150 standard
- Glass standard heating: 220V 100W/SQM (any other voltage and wattage available on demand)
- Aluminium frame standard heating: 220V 7.5W/LMT (any other voltage and wattage available on demand)
- Adjustable self-closing action by torsion bar
Standard heating master frame
- Silver satin aluminium insulated by RAL 9005 PVC covers
- Any frame is adapted to receive aluminium framed or full glass doors by LUVE TGD
- Available configurations: 1, 2, 3, 4 and 5 openings
- LED on board or LED pre-wired configuration available
Download
| LUVE TGD Standard Max Line | Leaflet | ENGLISH | Download |
